GRITTY GRITTY ED03/ ED04

Mainly for off-road use

FrontGRITTY ED03/ ED04 ED03

Tire Size Standard Rim(inch) Appr. Rim(inch) OD(mm) TW(mm) Remarks
2.75-21 45P W 1.60 1.40~1.85 688 79

80/100-21 M/C 51P W 1.85 1.60~2.15 702 90

RearGRITTY ED03/ ED04 ED04

Tire Size Standard Rim(inch) Appr. Rim(inch) OD(mm) TW(mm) Remarks
4.10-18 59P W 2.15 1.85~2.50 642 110

120/90-18 M/C 65P W 2.75 2.15~3.00 681 124

For SUZUKI DR-Z400

ED03(Front)/ ED04(Rear)

Manufacturer

HONDA

200cc
MTX200R
  • Front2.75-21 45P W 〈MCS01036〉
  • Rear4.10-18 59P W 〈MCS05461〉
MTX200R2
  • Front2.75-21 45P W 〈MCS01036〉
  • Rear4.10-18 59P W 〈MCS05461〉
XL200R (1985-)
  • Front2.75-21 45P W 〈MCS01036〉
  • Rear4.10-18 59P W 〈MCS05461〉
XL200R (1982-)
  • Front2.75-21 45P W 〈MCS01036〉
  • Rear4.10-18 59P W 〈MCS05461〉
XLR200R
  • Front2.75-21 45P W 〈MCS01036〉
  • Rear4.10-18 59P W 〈MCS05461〉
125cc
MTX125R
  • Front2.75-21 45P W 〈MCS01036〉
  • Rear4.10-18 59P W 〈MCS05461〉
NX125
  • Front2.75-21 45P W 〈MCS01036〉
  • Rear4.10-18 59P W 〈MCS05461〉
XL125R
  • Front2.75-21 45P W 〈MCS01036〉
  • Rear4.10-18 59P W 〈MCS05461〉
XLR125R
  • Front2.75-21 45P W 〈MCS01036〉
  • Rear4.10-18 59P W 〈MCS05461〉

YAMAHA

200cc
XT200
  • Front2.75-21 45P W 〈MCS01036〉
  • Rear4.10-18 59P W 〈MCS05461〉
125cc
DT125R
  • Front2.75-21 45P W 〈MCS01036〉
  • Rear4.10-18 59P W 〈MCS05461〉

SUZUKI

125cc
DR125S
  • Front2.75-21 45P W 〈MCS01036〉
  • Rear4.10-18 59P W 〈MCS05461〉
TS125R
  • Front2.75-21 45P W 〈MCS01036〉
  • Rear4.10-18 59P W 〈MCS05461〉
400cc
DR-Z400S
  • Front80/100-21 M/C 51P W 〈MCS09712〉
  • Rear120/90-18 M/C 65P W 〈MCS08747〉
250cc
RMX250S (1992-)
  • Front80/100-21 M/C 51P W 〈MCS09712〉
  • Rear120/90-18 M/C 65P W 〈MCS08747〉

KAWASAKI

250cc
SUPER SHERPA
  • Front2.75-21 45P W 〈MCS01036〉
  • Rear4.10-18 59P W 〈MCS05461〉
125cc
KMX125
  • Front2.75-21 45P W 〈MCS01036〉
  • Rear4.10-18 59P W 〈MCS05461〉

KTM

125cc
LC2 125
  • Front2.75-21 45P W 〈MCS01036〉
  • Rear4.10-18 59P W 〈MCS05461〉
